AK Series vertical (wall mounted) box
Sealing ring: polyurethane foaming sealing strip with reliable sealing performance
Slotted box edge: prevent dust and water from entering the box, and
It is well matched with the sealing ring to form protection for the box
Wall hanging hole: the back plate of the box has been drilled with holes for wall hanging, which is convenient for installation (single opening)
The box door is 25mm above the ground
There are grounding screws on the box door
2.5mm thick mounting plate with 20mm wide U-bend on both sides
It makes the mounting plate stronger, and it is also convenient to transport the three cables at the bottom of the box into the cover plate
Parallel control cabinet series
AP Bevel console series
Both the platform and the upper inclined plane can be processed by replacing them with stainless steel to increase the beauty and corrosion resistance
The front (rear) door can be opened to facilitate the installation of a built-in mounting plate
The door installation moulding with assembly holes punched shall be vertically welded on both sides of the door.
Product Recommendation
B-xiling Electrical
Shanghai Baixiling Electric Co., Ltd., located in Jinhui Town, Fengxian District, Shanghai, mainly produces AE case, AK wall mounted case, ES independent control cabinet, PS parallel cabinet, stainless steel cabinet, PC computer cabinet, machine tool cantilever system, DC cantilever box, DH, DF, DE operation box; AP ramp console, cabinet air conditioner, GA cast aluminum box, cabinet lamp, etc.
A joint-stock high-tech enterprise involving automatic process control, such as: industrial equipment frequency conversion group control system, various high-power motor group control soft start, elevator and boiler frequency conversion control system, air-conditioning refrigeration, cooling water pump, water supply pump frequency conversion group control system, building BAS system, electrical assembly OEM business, electrical complete system hardware system product development, manufacturing, sales and engineering technology services.
